Input Voltage for circuit

DC+12V

Input Voltage for device

Based on Input voltage for device

Standby

Display shows:00:00, reply: Normal Open (NO)

Max current load

15A for total

Basic working way

User inserts coins→ goes to balance→choose device to use by push button start→device start working

Check Balance

Push a button when stand by

Display

- Standby: shows 00:00

- Running Time: Shows remaining time
If more than 2 devices are running, user can hold on button start for seconds to check time

Insert coins

when time is running

- Credit goes to balance.

- Add time after user push button start.

Title

A

B

Description

Working way

01

01

Only 1 device can work simultaneously

02

1-4 devices can work simultaneously

Light for button

02

03

Lights all the time

04

Lights when devices can be used

05

Lights when devices are working

Time Type

03

06

Hour: Minute

07

Minute: Second

Memory

04

08

Yes, keeping running after re-power on

09

No, standby after re-power on

Back to Standby

05



ser has no action after push buttons or receive signals in setting time
Default: underline
