functioneaza perfect
se face proba si video

General

Manufacturer: Technics
Model: RS-BX 601
Type: Three-head stereo cassette deck with rear band control
Years of manufacture: 1994-1999
Made in: Japan
Color: Technics-anthracite
Power consumption: 23 W
Dimensions (W/H/D): 430 x 125 x 293 mm
Weight: 3.8 kg
Original price approx.: 550 DM

Connections

Inputs:
Line In (REC) 100 mV/47 kOhm
Outputs:
Line Out (PLAY) 500 mV/500 ohms.
Headphones 190 mV/8 Ohm (load impedance 8-600 Ohm)

Specifications

Audio head assembly:
recording head [Permalloy (combi head)] x 1
Playback head [Permalloy (combination head)] x 1

erase head [double-slit ferrite head] x 1
Motors:
Capstan: DC servo motor x 1
Coils: DC motor x 1
Cassette compartment open/close: DC motor x 1
Tape speed: 4.8 cm/s
Variation in synchronisation: 0.07% (effective), +-0.2% (DIN)
Rewind time: approx. 50 sec. with C 60 tape
Frequency response (Dolby NR Off):
Metal band: 30-19,000 Hz (+-3dB) / 20-20,000 Hz (DIN).
Chrome band: 30-18,000 Hz (+-3dB) / 20-19,000 Hz (DIN)
Normal band: 30-17,000 Hz (+-3dB) / 20-18,000 Hz (DIN)
External voltage distance: (signal level=full scale, chrome band)
without Dolby 57dB (A curve)
Dolby B 66dB (A-curve)
Dolby C 74dB (A-curve)

Special Features

Automatic tuning control (ATC, in three frequency ranges).
3 sound heads. The recording can be listened to directly via headphone output and monitor circuit. This also works with amplifiers with tape2/ monitor circuit.

Dolby B and C
Dolby HX-PRO
Adjustable headphone output
MPX filter (switchable)
Fast forward function
