Stare foarte bună de funcționare, înregistrare excelentă, derulări impecabile, nu face autostop.
Foto reale

General

Manufacturer: Teac
Model:Teac V-40, component of the Teac Prism 50 overall system Teac Prism 50
Type: Cassette Tape Deck
Years of manufacture: 1981 - 1984
Made in: Japan
Colour: Silver
Power consumption: 11 W
Dimensions: 432 x 110 x 255 mm (WxHxD)
Weight: 5.5 kg
Original price approx.: 600 DM
Number of inputs:
Line In: 60 mV, 50 kOhm
Line In DIN: 60 mV, 50 kOhm
Microphone: 0,25 mV, > 200 Ohm
Number of outputs:
Line Out: 300 mV, 50 kOhm
Line Out DIN: 30 mV, 50 kOhm
Headphone: 8 Ohm
Audio heads: 2 (1x record/playback, 1x erase)
Motor: 1
Synchronization fluctuations: 0.05 %
Tape types:
Frequency response:
Normal: 30 - 14'000 Hz, ± 3 dB.
Chrome: 30 - 15'000 Hz, ± 3 dB
Metal: 30 - 16'000 Hz, ± 3 dB
Distortion factor: 2.5
Signal-to-noise ratio:
Dolby Off: 57 dB (1 kHz)
Dolby B On: 67 dB above 5 kHz
Dolby: B
Premagnetization and erase frequency:
Rewind time: 110 seconds for C-60 cassette.
