Specifications
SKU
40229

HF Driver
1.4" (36mm) aluminum dome compression driver, 36mm Voice Coil Size, 1" (25mm) Exit Size, Neodymiu...

LF Driver
8" (203mm) aluminum cone, Santoprene surround, 60.55mm Voice Coil Size, Ferrite Magnet

Frequency Response (+/- 10db)
39.8Hz - 25kHz

Frequency Response (+/- 3db)
53.3Hz - 20kHz

Power Handling (RMS)
150 watts (600 watts peak), 100 hours

Sensitivity
93dB (2.83V/1m)

Enclosure
PC/ABS (UL94V-0), Steel, Powder coated

Rated Maximum SPL
112dB 1 meter (3.3 feet), 118dB peak

Nominal Impedance (Ohms)
8 ohms

Transformer Taps
70 V / 100 V: 120W, 60W and 30W 70 V: 15W

Coverage Pattern 1kHz to 10kHz
120 or 80 Degree Axis Symmetric

Dimensions (Diameter x D)
13.27" x 10.8" (337.06mm x 274.32mm)

Cut-Out Dimensions (Diameter)
11.625" (295.28mm)

Weight
26.04 lbs. (11.81kg)

Grille
Steel

Input Connector
Four pin, Euroblock with loop output connections

Certifications
UL 1480A, UL 2043, NFPA 90A, NFPA 70

Suspension Points
Two, on top surface

Maximum SPL (Peak)
118dB peak
