DVR Model 5208-H 5 in 1 Specification:
• Support TVI 2.0 720P/1080P/3MP, AHD 1.0/2.0 720P/1080P/3MP and CVI 720P/1080P
• 5 in 1: support TVI 2.0，AHD 1.0/2.0，CVBS，IPCAM, CVI
• 10 formats can be matched freely, no limitation of PAL&NTSC: TVI（720P-25/30/50/60fps，1080P-25/30fps, 3MP-18fps)，AHD（720P-25/30fps 1080P-25/30fps, 3MP-18fps)，CVBS 960H PAL/NTSC, CVI（720P-25/30fps 1080P-25/30fps）
• Support 600m BNC video output
• Support UTC

- CHANNEL MODE DVR Mode Support, Max 8ch: AHD-3.0MP/1080P/960P/720P; TVI-3.0MP/1080P/960P/720P; analog video real time input; Mixed Mode Support, Max 8ch，
Arbitrary proportion analog channels and IPCAM channel; NVR Mode Support, Max 8ch IPCAM video real time input

- DIGITAL CHANNEL (IPC) IP video input Max 8ch 1080P，RJ45 interface
buit-in switch NO
Protocol ONVIF, N1

- IPC Remote Setting Time synchronization setting/ encoding setting color adjust/ Motion detection

- ANALOG CHANNEL video input format TVI 2.0 (720P-25/30/50/60fps, 1080P-25/30fps, 3MP-18fps), AHD (720P-25/30fps, 1080P-25/30fps), CVBS (960H-PAL/NTSC)
video encoding resolution 3MP/1080P-12fps 1080P-H(960x1080)/720P-20fps; 960H/D1-25fps
video encoding rate 512 Kbps ~ 4Mbps
UTC support 8ch
Audio input support 2ch (8 CH optional)
Audio Encoding G.711

- VIDEO OUTPUT HDMI output 1 CH, HDMI Interface; Max Resolution: 1920x1080/60Hz
CVBS output Can support custom
VGA output 1 CH, VGA Interface; Max Resolution: 1920x1080/60Hz

- AUDIO OUTPUT Audio output RCA Audio output *1, HDMI Audio output

- PLAYBACK Stream type AV stream/video stream
Video Compression H.264
audio Compression G.711
Recording DVR mode: 8 CH 720P/Half-1080P/1080P Recording
Mixed mode or NVR mode: 8 CH 1080P Recording
Playback ４ CH 1080P Playback, 1 CH 3.0MP Playback

- DOUBLE STREAM Support

- WEB ACCESS Support

- PC CLIENT Support

- MOBILE PHONE CLIENT Support

- HARD DISK DRIVE Storage Type 1* SATA Interface (Can be extended to 2*SATA)
Storage Capacity 6TB/sata In Max
Backup USB Backup & Internet Backup
