With the Onix Beta XI2, Shanling presents the new version of their successful portable DAC. This new iteration retains the dual CS43198 DAC architecture that made its predecessor famous and combines it with JAN6418 tube amplification for a warm and smooth sound, typical of analogue.

With the Onix Beta XI2, Shanling presents the new version of their successful portable DAC. This new iteration retains the dual CS43198 DAC architecture that made its predecessor famous and combines it with JAN6418 tube amplification for a warm and smooth sound, typical of analogue.

Shanling Onix Beta XI2: 2 CS43198 DAC chips
The Onix Beta XI2 uses two Cirrus Logic CS43198 DAC chips, enabling it to support data streams up to PCM 32-bit 768kHz and DSD512. The two DAC chips work symmetrically to deliver clear and accurate sound reproduction.

Shanling Onix Beta XI2 : DAC chip
Shanling Onix Beta XI2 : TPA1612 tubes
Shanling Onix Beta XI2: Power tubes and OPA1612
The amplification stage of the ONIX Beta XI2 is based on a pair of OPA1612 op-amps coupled with BUF434A and JAN6418 power tubes. These tubes are renowned for their compact size, low power consumption and stable operation. The use of tubes provides warm, smooth sound reproduction. However, if you prefer more neutral reproduction with more pronounced dynamics, a transistor amplification mode is also available.

Shanling Onix Beta XI2: Aluminium housing
The Beta XI2 retains the characteristic aesthetics of the ONIX range and features a CNC-machined aluminium body combined with a 0.78-inch screen and three physical buttons for volume and playback control.

Shanling Onix Beta XI2 : Side view
Technical characteristics

Specifications
Product type Portable DAC and headphone Amplifier
Input 1x USB-C
Outputs 1x Balanced 4.4mm headphone jack output
1x Single-ended 3.5mm headphone jack output
DAC chips 2x CS43198
Supported sampling rates PCM up to 32bit 768kHz
Native DSD up to DSD512
Amplification components 2x JAN6418
2x TPA1612
4x BUF434A
Screen 0.87 inch
USB mode UAC 1.0
UAC2.0
Single-ended 3.5mm jack output (Transistors)
Output power Low gain : 45mW at 32Ω
High gain : 180mW at 32Ω
Total harmonic distortion more noise (THD+N) 0.0006% at 32Ω (A-Weight)
Dynamic range 124dB at 32Ω (A-Weight)
Channel Separation 73dB
Signal-to-noise ratio (SNR) 124dB at 32Ω (A-Weight)
Output impedance 0.3Ω
Single-ended 3.5mm jack output (Tubes)
Output power Low gain : 37mW at 32Ω
High gain : 152mW at 32Ω
Total harmonic distortion more noise (THD+N) 0.006% at 32Ω (A-Weight)
Dynamic range 122dB at 32Ω (A-Weight)
Channel Separation 73dB
Signal-to-noise ratio (SNR) 122dB at 32Ω (A-Weight)
Output impedance 0.3Ω
Balanced 4.4mm jack output (Transistors)
Output power Low gain : 180mW at 32Ω
High gain : 550mW at 32Ω
Total harmonic distortion more noise (THD+N) 0.0008% at 32Ω (A-Weight)
Dynamic range 128dB at 32Ω (A-Weight)
Channel Separation 107dB
Signal-to-noise ratio (SNR) 128dB at 32Ω (A-Weight)
Output impedance 0.6Ω
Balanced 4.4mm jack output (Tubes)
Output power Low gain : 152mW at 32Ω
High gain : 550mW at 32Ω
Total harmonic distortion more noise (THD+N) 0.006% at 32Ω (A-Weight)
Dynamic range 127dB at 32Ω (A-Weight)
Channel Separation 107dB
Signal-to-noise ratio (SNR) 127dB at 32Ω (A-Weight)
Output impedance 0.6Ω
General
Dimension 69.8 x 39 x 14mm
Weight 45.3g
Color Black
Package 1x Shanling Onix Beta XI2
1x USB-C to USB-C cable
1x USB-C to USB-A adapter
