Sursa noua carcase SFF Power supply TFX 300W Akyga AK-T1-300 P4 APFC FAN 3xSATA

Product code
AK-T1-300
Product type
Computer power supply
Format
TFX
Series
Ultimate
Responsible Entity
Akyga Europe Sp. z o.o., 52-200 Suchy Dwór, Wroc awska 1c, Polska Poland
Supply voltage
230 V
Power consumption
3 A
Efficiency
> 80 %
80 PLUS compatibility
Yes
Current on the +3.3V rail
15 A
Current on the +5V rail
15 A
Maximum load on +3.3V and +5V line
100 W
Current on the +12V rail
20 A
Maximum load on 12V line
240 W
Maximum power
300 W
Power inlet
IEC C14
Mainboard Power Connector
24-pin
Power connector EPS12V 8 pin
1 pc ( 4 + 4-pin )
Power connector PCI-E 6 pin
None
Power connector PCI-E 6+2 pin
None
Power connector PCI-E 8 pin
None
Molex connector
1 pc
Mini-Molex connector
None
SATA connector
3 pcs
PFC filter
Active
Ground wire
Yes
OVP
Yes
OCP
Yes
OPP
Yes
OTP
Yes
SCP
Yes
UVP
Yes
Fan size
80 mm
Fan adjustments
Automatic
Cable length
8 -36 cm
Power cable included
None
Material
Galvanized steel
Product color
Grey
MTBF
100000 h
Temperature
5 - 50 C
Package
Foil
Product size (L x W x H)
175 x 85 x 65 mm
Package size (L x W x H)
252 x 110 x 68 mm
Net weight
836.4 g
Gross weight
846.4 g
CE compatibility
Yes
FCC compatibility
No
RoHS compatibility
Yes
REACH compatibility
Yes
EAN code
