ADVANCED FEATURES
• HDMI® Video Upscaling to 4K with Qdeo™ Technology
by Marvell
• 4K Passthrough from Compatible Source Devices via HDMI
• Built-in Wi-Fi-Certified Wireless LAN Capability
• Bluetooth Version 2.1 + EDR Capability (Compatible
Profile: A2DP v1.2, AVRCP v1.3)
• Three-Stage Inverted Darlington Circuitry for Front
and Center Channels
• Rearside MHL™ for 1080p Video and Stills from
Smartphone and Tablet
• Internet Radio and Music Streaming Service Connectivity
(TuneIn Radio, Pandora®, Rhapsody, Slacker™, SIRIUS
XM Internet Radio®, Last.fm, Spotify, and AUPEO!)*1
• Playback of Audio Files Over Wireless Home
Network (MP3, WMA, WMA Lossless, FLAC, WAV, Ogg
Vorbis, AAC, Apple Lossless, DSD, LPCM*2, and Dolby®
TrueHD)
• Supports Onkyo Remote Apps for iPod touch®/iPhone®*3
and Android Devices*4
• Picture-in-Picture Input Video Preview with InstaPrevue™
Technology
• Phase-Matching Bass Boost
• Audyssey MultEQ® for Room Acoustic Correction
• Dolby® Pro Logic® IIz Upmixing for Seven-Channel
Surround Sound
• Overlaid On-Screen Display (OSD) via HDMI with
Quick Set-Up and Home Menu
• Powered Zone 2 and Zone 2 Line-Out for Distributed
Audio Playback in Another Room
• Hybrid Standby Power-Saving for Video and Network
Connectivity in Standby
• Smart Grid-Ready
• Bi-Amping Capability for Front Channels
*1 Availability of services depends on region. Some services may require a
firmware update. Availability of third-party services advertised here is accurate at
the time of publication, but may be subject to change without notice. *2 LPCM
is available via DLNA only. *3 Compatible with iPod touch (3rd generation or
later) and iPhone 3GS or later. All models require iOS 4.2 or later. *4 Requires
Android OS 2.1 or later.
AMPLIFIER FEATURES
• 95 Watts per Channel (8 Ohms, 20 Hz–20 kHz,
0.08% THD, 2 Channels Driven); 115 Watts per
Channel (6 Ohms, 1 kHz, 0.7% THD, 2 Channels Driven)
• WRAT (Wide Range Amplifier Technology)
• H.C.P.S. (High Current Power Supply) Massive High Power Transformer
• Discrete Output Stage Circuitry
• Optimum Gain Volume Circuitry
• PLL (Phase Locked Loop) Jitter-Cleaning Circuit
Technology for S/PDIF Audio
PROCESSING FEATURES
• HDMI Support for 3D, Audio Return Channel,
DeepColor™, x.v.Color™, LipSync, Dolby TrueHD,
DTS-HD Master Audio™, DVD-Audio, Super Audio
CD, Multichannel PCM, and CEC
• TI Burr-Brown 192 kHz/24-Bit DAC for All Channels
• Advanced 32-Bit Processing DSP Chip
• 4 DSP Modes for Gaming: Rock, Sports, Action, and RPG
• Advanced Music Optimizer for Compressed Digital
Music Files
• Theater-Dimensional Virtual Surround Function
• CinemaFILTER™
• Direct Mode
• Double Bass Function
• Non-Scaling Configuration
• A-Form Listening Mode Mem
