Type Cassette deck
Heads One read / write head
Erase Head x1
Motor One electronically controlled DC servo motor with built-in generator
Quick winding speed 85 seconds or less (at C-60)
Uneven rotation 0.05% or Less (WRMS)
Frequency characteristic General, LH Tape : 25 Hz ~ 15kHz/30Hz ~ 14 kHz ± 3 dB
Ferrichrome Tape : 25 Hz ~ 17kHz/30Hz ~ 16 kHz ± 3 dB
Chrome Tape : 25 Hz ~ 17kHz/30Hz ~ 16 kHz ± 3 dB
Signal-to-noise ratio Dolby OFF : 54 dB or more (General / LH Tape)
Dolby ON : 64 dB or More (5 kHz or More, General / LH Tape)
* When chrome tape is used, it is further improved by 4.5 db (5 khz or more).
Distortion factor 1.5% or less (0 dB)
Operating part Direct change system
Input
(Sensitivity / Maximum allowable input / Impedance) Mic : 0.3mV/100mV/10k Ω, 0.6 mm φ Jack
(Applicable Impedance 250 Ω ~ 10k Ω)
Line : 65mV/25V/100k Ω, Pin Jack
Output
(Reference Level / Maximum Level / Impedance) Line : 450mV/800mV/50k Ω, Pin Jack
Headphones : 60mV/100mV/8 Ω, 6 mm φ Stereo Jack
Accessory function Dolby System (with LED display)
Dynamic level meter
Continuously variable bias adjustment mechanism (meter display)
Peak level meter (during playback)
Equalizer selector switch (STD, Fe-Cr)
Automatic switching mechanism of CrO2
Input selector (LINE/MIC)
Memory Stop
Timer standby mechanism
Cassette rear illumination lamp
Semiconductor used IC : 4
Transistor : 38 pcs (For Motor Control : 3 pcs)
Diode : 52 Pieces (For Motor Control : 1 Piece)
Zener diode : 1 unit
Pwer 100 VAC, 50Hz/60Hz
Power consumption 15W
External dimensions Width 420x Height 187x Depth 304 mm
Width 480x Height 187x Depth 322 mm (when JA-R102 is attached)
Weight 8.5kg
Sold Separately Rack-Mount Adapter JA-R102 (¥ 3,600)
