perfect functional
se face proba si video

General:

Manufacturer: Onkyo
Model: TA-2550 - [Integra Series]
Type: Cassette Tape Deck
Years of manufacture: 1988 - 1990
Made in: Japan
Color: silver, black - wooden side panels as option
Remote control: solo no, but optional system remote control via other devices
Power consumption: 19 watts
Dimensions: 435 × 132 × 366 mm (W×H×D)
Weight: 5,8 Kg
Original price approx. 850,- DM

Connections:

Number of inputs:
Line 2x (Cinch) - 60 mV
DIN 1x

Number of outputs:
Line 2x(Cinch) - 500 mV
DIN 1x

Headphones: 6.35mm jack (Recommended termination impedance: 8-200 Ohm)

Technical Data:

Sound heads: 3 - Double Special Hartpermalloy 1x for combined recording and playback, 1 x erase (ferrite)
Motors: 3 - DC servo 1x/ 2x DC
Tape speed: 4.8 cm / s
Synchronization fluctuations: 0.045 % (effectively evaluated)
Extinguishing principle: HF extinguishing
Tape types: type I = standard, type II (CrO2) = HIGH, type IV = metal (pure iron).
Frequency response:
Type I: 20 - 17000 Hz ± 3 dB
Type II: 20 - 18000 Hz ± 3 dB Type IV: 20 - 20000 Hz ± 3 dB

Noise floor:
without Dolby NR 60 dB (pure iron).
with Dolby B improvement of 10 dB above 5 kHz and 5 dB at 1 kHz
with Dolby C enhancement by 20 dB at 5 kHz.
Auto-Reverse: No
Title search: Yes
Dolby: B/C
MPX Filter: yes, switchable
Monitor / Source: yes
