Vând amplificator Onkyo A 5 în stare foarte bună tehnic și estetic, sunet excepțional, totul original fără nici o intervenție, adus din Germania! Trimit și prin curier cu verificare! Am și alte modele, vizionați anunțurile mele! Onkyo A-5

Manufacturer: Onkyo
Model: A-5
Type: Integrated amplifier
Years of manufacture: 1976 - 1979
Made in: Japan
Color: Silver
Remote control: No
Power consumption:
Dimensions: 444 x 159 x 380 mm (WxHxD).
Weight: 12,2 Kg
Original price approx.: 998 DM

Connections

Number of inputs 6:
Phono 1 + 2: 2.5 mV, 50 kOhm, ( MC: 100 µV, 20 Ohm.
Tuner, Aux: 150 mV, 50 kOhm
Tape 1 + 2: 150 mV, 50 kOhm
Number of outputs 3:
Pre Out: 1.5 V, 2.7 kOhm
Tape 1 + 2: 150 mV, 2.5 kOhm

Technical Data

Continuous power (at distortion)
8 Ohm: 2 x 45 Watt
4 Ohm: 2 x 70 Watt
Dynamic power
8 Ohm:
4 Ohm:
Total harmonic distortion: 0.08 %
Attenuation factor: 50
Frequency response: 15 - 40'000 Hz
Signal-to-noise ratio:
Phono: 75 dB
High level: 90 dB
Tone control:
Bass: ±10 dB/100 Hz
Treble: ±10 dB/10 kHz

Turnover bass: 125 Hz, 400 Hz
Turnover treble: 2 kHz, 8 kHz
Loudness (-40 dB): +5 dB/100Hz +5 dB/10 kHz
High Filter: 6 kHz (12 dB/octave)
Low Filter (Subsonic): 10 Hz (12dB/octave)
Mute: yes, -20 dB
Direct/Line-Straight: yes

Special Features

Pre- and power amplifier separable
