intrare video IP: 8-canale
Audio bi-directional 1-canal, RCA (2.0 Vp-p, 1kΩ)
Retea
Bandwidth intrate: 50Mbps
Bandwidth iesire: 80Mbps
Iesire Video/Audio
Iesire HDMI/VGA: 1-canal, rezolutie:
1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz,
1024 × 768 /60Hz
Rezolutie inregistrare: 5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Frame Rate: Main stream: 50 fps (P) / 60 fps (N)
Sub-stream: 50 fps (P) / 60 fps (N)
Iesire Audio: 1-canal, RCA (Linear, 1kΩ)
Decodare
Live view / Playback: 5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Hard Disk
SATA: 2 SATA
Capacitate: 4TB
Interfata externa
Interfata retea: 1RJ-45 10/100/1000Mbps self-adaptive Ethernet interface
Interfata USB: 1 × USB 2.0 and 1 × USB 3.0
Intrare Alarma: 4-ch
Iesire Alarma: 1-ch
POE
Interfata: 8 interfete de retea independente100 Mbps PoE
General
Alimentare: 220V DC
Consum(fara hard disk si POE): ≤ 10W
Temperatura operare: -10 ºC ~ +55 ºC
Umiditate operare: 10 % ~ 90 %
Dimensiuni: 445 x 290 x 45 mm
Greutate(fara HDD): ≤ 1 Kg (
