Memoria RAM Kingston HyperX Savage DDR4-2400 8GB CL12 este o alegere excelentă pentru configuratii single channel. Cu performanțe superioare și fiabilitate garantată, această memorie RAM este ideală pentru îmbunătățirea performanței calculatorului tău. Descoperă viteza și eficiența acestui produs de înaltă calitate!

DESCRIPTION

HyperX HX424C12SB2/8 is a 1G x 64-bit (8GB) DDR4-2400 CL12 SDRAM (Synchronous DRAM) 2Rx8, memory module, based on sixteen 512M x 8-bit FBGA components. Each module supports Intel XMP (Extreme Memory Profiles). Each module has been tested to run at DDR4-2400 at a low latency timing of 12-14-14 at 1.35V. The SPDs are programmed to JEDEC standard latency DDR4-2133 timing of 15-15-15 at 1.2V. Each 288-pin DIMM uses gold contact fingers. The JEDEC standard electrical and mechanical specifications are as follows:

XMP TIMING PARAMETERS

• JEDEC: DDR4-2133 CL15-15-15 1.2V
• XMP Profile #1: DDR4-2400 CL12-14-14 1.35V
• XMP Profile #2: DDR4-2133 CL13-13-13 1.2V

SPECIFICATIONS
CL(IDD): 15 cycles
Row Cycle Time (tRCmin): 46.5ns (min.)
Refresh to Active/Refresh Command Time (tRFCmin): 260ns (min.)
Row Active Time (tRASmin): 33ns (min.)
Maximum Operating Power: TBD W*
UL Rating: 94 V - 0
Operating Temperature: 0 C to +85 C
Storage Temperature: -55 C to +100 C
*Power will vary depending on the SDRAM used.

FEATURES
• Power Supply: VDD = 1.2V Typical
• VDDQ = 1.2V Typical
• VPP - 2.5V Typical
• VDDSPD = 2.25V to 3.6V
• On-Die termination (ODT)
• 16 internal banks; 4 groups of 4 banks each
• Bi-Directional Differential Data Strobe
• 8 bit pre-fetch • Burst Length (BL) switch on-the-fly BL8 or BC4(Burst Chop)
• Height 1.36” (34.57mm)
