Amplificator integrat Luxman L-505u in stare excelenta cu telecomanda!

Model pentru piata japoneza la 100V, se livreaza cu transformator extern tot japonez, 230v-100v ultra-silentios, de calitate audio-grade de la Kashimura, toroidal cu putere min 550W.
Acest model a fost fabricat in 2 versiuni una cu fata silver (Blaster White) si VUmetre albastre si cealalta (care este acum la vanzare) cu fata Champagne-Gold si VUmetre galbene, mult mai rar de gasit, selectie extrem de cautata printre audiofili.

Preluare din Cluj-Napoca cu proba si auditie prealabila, sau posibilitate de livrare in Bucuresti zona iesirii A1 prin sofer TIR cu curse saptamanale care transporta exclusiv in cabina aparatul, experienta il manipulare colete fragile.

audio-database.com/LUXMAN/amp/l-505u-e.html
Model Rating
Type Pre-main amplifier
Continuous effective output 140W + 140W (4 Ω)
100W + 100W (8 Ω)
Input Line 4 system
Phono 1 System (MM/MC Switching)
Balance line 1 system
Recording input / output Line 2 system
Pre-output and main input 1 system each
Speaker output Routes A and B2
Amplifier circuit ODNF2.2
Output configuration Bipolar parallel PP
Power transformer EI Type 440 va
Total harmonic distortion factor 0.005% or Less (8 Ω, 1 kHz)
0.03% or Less (8 Ω, 20 Hz to 20 kHz)
Input Sensitivity / Impedance Phono MM : 2.5mV/47k Ω
Phono MC : 0.3mV/100 Ω
Line : 180mV/42k Ω
Bal. Line : 180mV/79k Ω
Main in : 1V/51k Ω
Output voltage Recorder:180mV
Pre out:1V
S/N ratio (IHF-A) Phono MM : 91 dB or more
Phono MC : 75 dB or more
Line : 105 dB or more
Frequency characteristic Phono : 20 Hz to 20 kHz ± 0.5 dB
Line : 20 Hz to 100 kHz + 0 -3.0 dB
Damping factor 110
Tone Control Maximum Change Bass : ± 10 dB (100 Hz)
Treble : ± 10 dB (10 kHz)
Attachment Front Panel Side
Power meter
Headphone jack
Fono MC
Recording selector
Speaker selector
Mode selector
Tone control
Balance
Straight Line
Subsonic
Separate
Rear Panel Side
Balanced phase inverter
Line phase sensor
AC inlet
AC outlet Non-Interlock : 2 systems, total maximum 300W
Power supply voltage 100 VAC, 50Hz/60Hz + TRANSFORMATOR EXTERN 230V-100V
Power consumption 210W (Electrical Appliances and Materials Safety Act)
82W (no signal)
1.2W (standby)
External dimensions Width 467x Height 179x Depth 437 mm
Weight 21.0kg
Attachment Remote control
Power Cable (JPA-10000)
