Connections

Number of inputs:
Input sensitivity:
Phono MM: 2.3 mV, 47 kOhm, 250 mV max.
Line: 145 mV, 23 kOhm Tuner: 145 mV, 23 kOhm AUX: 145 mV, 23 kOhm

Tape Play 1, 2: 145 mV, 23 kOhm
Number of outputs:
Outputs:
Tape Rec 1, 2: 145 mV, 23 kOhm
Tape Rec DIN: 30 mV
Headphones:

Specifications

Frequency response:
Phono (RIAA): 20 - 20'000 Hz, ± 0.2 dB.
High level: 10 - 100'000 Hz, + 0 dB, - 1 dB Signal-to-noise ratio:

Phono: 90 dB
High level: 106 dB

Tone control
Bass: ± 8 dB at 100 Hz
Treble: ± 8 dB at 10 kHz

Loudness (Bass Contour): + 10 dB at 50 Hz
High Filter (High Cut): 6 kHz, 6 dB / octave
Low Filter (Subsonic): 15 Hz, 6 dB / octave

Special Features

Tone control via jog keys
