FortiGate ® /FortiWiFi ™ -60C Series
Integrated Threat Management for
Frontline Locations
Enterprise-Class Protection for Remote Offices, Retail, and Customer Premise Equipment
FortiGate/FortiWiFi-60C series of consolidated security appliances deliver
comprehensive enterprise-class protection for smaller locations, branch offices,
customer premise equipment (CPE) and retail networks. An integrated set of
essential security technologies deployed in a single device protects all of your
applications and data. Simple per-device pricing, an integrated management
console, and remote management capabilities significantly reduce your
procurement, deployment and administration costs.
Comprehensive Protection and Optional Wireless Capability
FortiGate consolidated security appliances deliver an unmatched range of security
technologies. They integrate essential firewall, IPSec and SSL VPN, application
control, intrusion prevention, antivirus, and web filtering protection into a single
device at a single price, all managed from a "single-pane-of-glass" console. They
also include other security technologies, such as data loss prevention (DLP),
encrypted SSL inspection, endpoint NAC, WAN optimization, and vulnerability
management. In addition, Fortinet’s FortiGuard® Labs is on duty around the clock
and around the world, monitoring changes in the threat landscape. FortiGuard Labs
deliver dynamic threat updates to protect your network against emerging threats.
FortiWiFi-60C/CM/CX appliances deliver the protection and performance you need
with the convenience of wireless networking. Dual-band capabilities and support
for 802.11a/b/g/n standards ensure compatibility with your existing network
infrastructure. Multiple SSID support allows you to create multiple wireless access
networks, enabling unencrypted guest or contractor access to the Internet while
limiting access to corporate networks.
Purpose-Built Performance and Reliability
Fortinet’s purpose-built hardware and software prevent your network security
from becoming your network bottleneck. Custom FortiASIC processors maximize
throughput while blocking unauthorized access and eliminating unwanted traffic
from your network. The purpose-built FortiOS operating system gives you
unmatched flexibility to deploy the technology you need to enforce your security
policies.
Industry Certifications
FortiGate/FortiWiFi-60C
Series Benefits
• Comprehensive protection
against network, content, and
application-level threats
• Segmentation of internal traffic
and full security for perimeter-
bound traffic
• Fortinet's purpose-built FS1
SoC processor delivers Gigabit
firewall throughput
• GbE switched internal ports
with dedicated WAN and DMZ
ports
• ADSL-A interface delivers high-
speed consolidated DSL router
and security gateway
• Internal storage enables local
log records and graphical
reports
• WAN optimization and web
caching improve network
performance
• ExpressCard support and
USB-based wireless broadband
allow fast deployment of
secure networks
• FortiExplorer setup utility
provides easy setup and
configuration
DATASHEET
FortiGate
FortiGate
FortiGate
Remote Office
Remote Office
Headquarters
FORTIGATE IN THE DISTRIBUTED ENTERPRISE
INTERNAL I/O
PCIe / RAM / FLASH
EXTERNAL I/O
ETHERNET / SERIAL / USB
FORTIASIC
NETWORK
PROCESSOR
FORTIASIC
CONTENT
PROCESSOR
RISC-BASED
GENERAL
PURPOSE
PROCESSOR
The Fortinet FS1 System-on-a-Chip
The FortiGate/FortiWiFi-60C series represent a new
generation of desktop network security appliances from
Fortinet, and include the first Fortinet System-on-a-chip
(SoC), the FS1. Integrating FortiASIC acceleration logic
together with a RISC-based main processor and other
system components, the FS1 SoC simplifies appliance
design and enables breakthrough performance for smaller
networks.
The FS1 and resulting FortiGate/FortiWiFi-60C series
appliances allow large distributed enterprises to provide
integrated, multi-threat protection across all points on their
network without sacrificing performance
