- Stare Perfecta de Functionare,sunet f f bun,totul original la interior,fara reparatii -

General
Brand: Denon
Model: DR-M 24 HX
Color: Black, Silver
Years of manufacture: 1987-1988
Original price: 900 DM
Dimensions (W x H x D): 435 x 117 x 286 mm
Weight: 5,6 Kg
New price approx.: 900 DM, 1988

Connections
Inputs: 1
RCA (Cinch) Stereo

Outputs: 2
RCA (Cinch) Stereo

Headphone output (6.3 mm jack, controllable with output level)

Technical data
Closed Loop Dual Capstan Drive
3 heads (recording/playback head is a Sendust ferrite head)
3 motors, two of them for the drive, one small servo motor for auxiliary services (sensor keys, head carriage)
Automatic tape type detection
Dolby HX PRO
Dolby B and C Noise Reduction
MPX filter (switchable)
Output Level - simultaneous adjustment of the output power at line out
Frequency response: on metal cassette (IEC IV): 25- 20,000 Hz +/- 3dB, at -20 dB
Uniformity: only 0.04 % DIN, evaluated (cf. Audio 4/1988, p.22). 0.045 % WRMS
Rewinding of a C60 cassette: approx. 90 sec., of a C90 cassette: approx. 130 sec. (Audio 4/1988, p.22)
Signal-to-noise ratio (Dolby C): more than 75 dB (CCIR/ ARM)

Channel separation: more than 40 dB (at 1 kHz)
Crosstalk attenuation: more than 65 dB (at 1 kHz)
Power consumption: 18 W
