Wheel Size
29"
Frame Material
Carbon Fiber
Frame Material Details CFR (Canyon Factory Racing) carbon front and rear triangles; chainstay, seatstay, and down tube protection
Rear Travel
200mm
Rear Shock FOX DHX2 Factory, high/low-speed compression adjust, high/low-speed rebound adjust, 250mm x 75mm
Fork FOX FLOAT 40 Factory, GRIP2 damper, high/low-speed compression adjust, high/low-speed rebound adjust
Fork Travel 203mm
Head Tube Diameter Straight, 1.5"
Headset ACROS AZX-227
Handlebar Canyon G5 Riserbar, aluminum, 800mm width, 20mm rise
Stem Canyon G5, 45mm length
Grips Canyon G5
Brakes SRAM Code RSC, 4-piston, SRAM CenterLine 220mm 6-bolt rotors
Brake Levers SRAM Code RSC, tool-free reach and contact point adjust
Drivetrain
1x
Shifters SRAM X01 DH, 7-speed
Front Derailleur None
Rear Derailleur SRAM X01 DH, 7-speed
ISCG Tabs ISCG05
Chainguide e*thirteen LG1+; upper slider, lower pulley, and bashguard
Cranks SRAM X01 DH DUB, 165mm length
Chainrings SRAM X01 DH, 34 tooth
Bottom Bracket SRAM DUB, English/BSA threaded
Pedals None
Chain SRAM PC-1110, 11-speed
Cassette SRAM XG-795 DH, 7-speed, 10-24 tooth
Rims DT Swiss FR560, 30mm inner width
Hubs DT Swiss 240, 20x110mm front, 12x157mm rear with Ratchet EXP freehub and XD driver
Spokes DT Swiss wheelset
