Specificatii

Format ATX
CPU Socket AM4
Chipset AMD B550
Procesoare suportate AMD Ryzen™ din a 3-a generatie
Socket procesor 1

Memorie

Tip memorie DDR 4
Capacitate maxima memorie RAM 128 GB
Frecventa memorie (MHz) 5100(O.C)/4800(O.C.)/4600(O.C)/4400(O.C)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3600(O.C.)/3466(O.C.)/3200/3000/2800/2666/2400/2133
Suport Dualchannel Da
Suport ECC Variaza in functie de CPU
Sloturi memorie 4

Conectivitate

Slot PCI PCI Express x16 4.0
Audio integrat ROG SupremeFX 8-Channel High Definition Audio CODEC S1220A
LAN integrat Intel® I225-V 2.5Gb Ethernet
RAID integrat 0, 1, 10
Conectivitate 1 x Optical S/PDIF OUT
1 x RJ-45
5 x Audio Jacks
1 x DisplayPort
2 x USB 2.0
4 x USB 3.2 gen 1
2 x USB 3.2 Gen 2 (1 x Type-A+1 x USB Type-C®)
1 x HDMI
Interfata Serial ATA 6 x SATA
Rata de transfer SATA 750 MB/s
Conector sursa (pini) 1 x 4 pin ATX 12V
1 x 8 pin ATX 12V
1 x 24 pin EATX

Sloturi

Sloturi PCI-E x16 1
Sloturi PCI-E x1 3
Sloturi speciale 2 x M.2

Altele

Tehnologii suportate ASUS Q-Design
ASUS Exclusive Features
ASUS EZ DIY
Asus AURA RGB
ROG Exclusive Software
BIOS & memorie BIOS 256 Mb Flash ROM, UEFI AMI BIOS
Dimensiuni (L x W) (cm) 30.5 x 24.4
