KIT INSTALARE INCLUS!

LIVRARE PRIN CURIER RAPID IN TOATA TARA!

Categorii: Aparate aer conditionat, Aparate aer conditionat 12000 BTU Etichete: ( ALB ), + Kit instalare inclus, 12000 BTU, A++/A+, Aparat de aer conditionat, Auto Clean, Cold Plasma+, Gree Pulsar, GWH12AGBXB-K6DNA1A, I Feel, Inverter, Wi-Fi

Tabel cu specificatii tehnice pentru Gama Pulsar

Model U.M. GWH09AGAXB-K6DNA1B GWH12AGBXB-K6DNA1A GWH18AGD-K6DNA1D GWH24AGD-K6DNA1C
Functie Racire/Incalzire Racire/Incalzire Racire/Incalzire Racire/Incalzire
Capacitate min/nom/max Racire Btu/h 1706/8530/11089 3071/10918/12283 3412/15700/18084 6100/21000/23500
Incalzire Btu/h 1706/9554/12283 3071/11600/13648 2388/17742/19278 4400/22000/27000
SEER/SCOP (W/W) W/W 6.60 / 4.10 6.10 / 4.00 6.40 / 4.00 6.80 / 4.00
Clasa de energie Racire/Incalzire A++/A+ A++/A+ A++/A+ A++/A+
Alimentare Ph-V-Hz 1 Ph-220V–240V-50Hz 1 Ph-220V–240V-50Hz 1 Ph-220V–240V-50Hz 1 Ph-220V–240V-50Hz
Putere electrica min/nom/max Racire W 150/680/1300 220/991/1300 420/1355/1800 450/1786/2100
Incalzire W 140/730/1500 220/916/1500 420/1340/1900 450/1645/2200
Curent Nominal Racire A 7.50 7.50 9.00 9.70
Incalzire A
Debit de aer T/H/M-H/M/M-L/L/S m3/h 500/470/430/390/320/270/250 590/520/480/400/350/320/280 910/850/78*******00/650/610 1050/950/800/75*******50/600
Capacitate dezumidificare L/h 0.60 1.40 1.80 1.80
Interval temperatura exterioara de functionare (Min-Max) Racire ºC (-15 ~ 43) (-15 ~ 43) (-15 ~ 43) (-15 ~ 43)
Incalzire ºC (-15~ 24) (-15~ 24) (-15~ 24) (-15~ 24)
Unitate interioara
Nivel de Presiune Acustica T/H/M-H/M/M-L/L/S dB/A 38/36/34/32/28/25/21 41/37/35/33/30/26/24 44/39/37/34/32/30/29 46/42/40/37/35/32/30
Nivel de Putere Acustica T/H/M-H/M/M-L/L/S dB/A 55/48/46/44/40/37/33 56/49/47/45/42/38/36 57/52/50/47/45/43/42 63/59/57/54/53/49/47
Dimensiune neta LxlxH mm 704x185x260 779x185x260 982x221x311 982x221x311
Dimensiune bruta LxlxH mm 753x332x258 828x332x258 1044x385x297 1044x385x297
Greutate neta/bruta kg 7.50 / 9.00 8.00 / 9.50 13.50 / 16.00 14.00 / 16.50
Unitate exterioara
Nivel de Presiune Acustica dB/A 50 52 55 57
Nivel de Putere Acustica dB/A 60 63 65 65
Dimensiune neta LxlxH mm 732x330x555 732x330x555 732x330x555 873x376x555
Dimensiune bruta LxlxH mm 794x376x615 794x376x615 794x376x615 951x431x620
Greutate neta/bruta kg 25.00 / 27.50 25.00 / 27.50 26.50 / 29.00 36.50 / 39.50
Refrigerant R32 R32 R32 R32
Traseu frigorific
Diametru (lichid/gaz) mm 6.00/9.52 6.00/9.52 6.00/9.52 6.00/12
Lungime maxima m 15 20 25 25
Diferenta maxima de nivel m 10 10 10 10
Agent frigorific
Tip R32 R32 R32 R32
Cantitate Kg 0.48 0.55 0.75 1.18
Kit de instalare Da Da Nu Nu
Modalitate alimentare unitate exterioara unitate exterioara unitate exterioara unitate exterioara
Capac protectie supape (unitate exterioara) DA DA DA DA
