Antena Cisco Aironet Ceiling Mount Antenna 2.4 GHz 2dBi/5 GHz 4dBi - AIR-ANT2524V4C-R=

Technical Specifications


Antenna type

4-Element, Dual-band, Low Profile Omni



330578.eps
Operating frequency ranges

2400–2484 MHz
5150–5850 MHz

VSWR

2:1 or less in both bands

Peak gain

2.4-GHz band: 2 dBi
5-GHz band: 4 dBi

Polarization

Linear

Azimuth plane 3 dB beamwidth

Omni-directional

Elevation plane 3 dB beamwidth

2.4 GHz band: 69°
5 GHz band: 60°

Length

7.25 in (18.4 cm)

Width

7.25 in (18.4 cm)

Depth

1 in (2.5 cm)

Weight

1.3 lb (0.59 kg)

Cable

3 ft (91.4 cm) plenum rated, UV stable

Connector

RP-TNC

Environment

Indoor

Temperature range

32–133°F
(0–56°C)
