Preamplificator Rotel model Rotel RC-980 BX si amplificator Rotel model Rotel RB-960 BX Stereo (Dual Mono)
Model: RC-980 BX
Type: Preamplifier
Years of manufacture: 1992 - 1997
Made in: Japan
Color: Black
Remote control:
Power consumption: 10 watts
Dimensions: 440 x 70 x 325 mm (WxHxD)
Weight: 4.1 kg
Connections

Number of inputs:
Phono MM: 2.5 mV / 47 kOhm, 160 mV max.
Phono MC: 0.25 mV / 100 Ohm, 16 mV max. CD: 150 mV / 18 kOhm, 5 V max. Tuner: 150 mV / 18 kOhm, 5 V max. AUX: 150 mV / 18 kOhm, 5 V max.

Tape 1, 2 Play: 150 mV / 18 kOhm, 5 V max.
Number of outputs:
Tape 1, 2 Rec:
Pre Out: 1 V / 100 Ohm
Headphones:

Specifications

Frequency Response:
Phono (RIAA): 20 - 20'000 Hz, ± 0.2 dB.
High level: 4 - 100'000 Hz, ± 0,5 dB

Distortion factor: 0.004 %
Signal-to-noise ratio:
Phono MM: 75 dB
Phono MC: 70 dB
High level: 100 dB
Stereo channel separation

Manufacturer: Rotel
Model: RB-960 BX
Type: Power Amplifier
Years of manufacture: 1992 - 1997
Made in: Japan
Color: Black
Remote control:
Power consumption: 300 watts
Dimensions: 440 x 92 x 334 mm (WxHxD)
Weight: 9.2 kg
Connections

Number of inputs: 1
Line In: 1,0 V / 33 kOhm

Number of outputs:
1 pair of speakers

Technical Data

Continuous power (at distortion factor)
8 Ohm: 2 x 60 Watt RMS (20 - 20'000 Hz, 0,1 %)
4 Ohm: 2 x 110 Watt (1 kHz, 1 %)
Continuous power BTL Mono (with distortion factor)
8 Ohm: 1 x 180 Watt
Dynamic power:
8 Ohm:
4 Ohm:
Total harmonic distortion: 0.1 %
Attenuation factor: 280 (20 - 20'000 Hz, 8 Ohm)
Frequency response: 4 - 100'000 Hz (+ 0,5 dB / - 3 dB)
Signal-to-noise ratio: 116 dB (IHF, A network)

Special Features

BTL Mono bridgeable
sunt in stare perfecta de functionare ,sunet de exceptie .
