Amplificator Onkyo Integra A-8450: 8 intrari, 4 iesiri, impedanta 4-16 ohmi, 330 W consum din retea, reglaje bass, treble, balance, contrabass, muting, volum pozitionat central, prezinta unele zgarieturi, Phono Selector, functioneaza OK, made in Japan.

General

Manufacturer: Onkyo
Model: A-8450
Years of construction: 1988
Type: Integrated Amplifier
Remote Control: No
Power: 330 Watts
Dimensions: 435 × 147 × 388 mm (W × H × D)
Weight: 11.2 kg
Color: black / silver
Factory price approx .: 700.-DM

connections

Number of inputs: 6 (RCA)
Phono (MM / MC)
tuner
CD
2 x Aux (VCR and VDP)
2 × Tape
Number of outputs: 3
Headphones (6.3 mm jack)
2 × Tape Rec.
2 × Speakers

Technical specifications

RMS power:
2 x 155 watts into 4 ohms, 2 x 103 watts into 8 ohms
80 watt min. (Effectively) into 8 ohms, both channels driven, from 20 Hz to 20,000 Hz, with a THD of more than 0,008%
Output Power:
2 x 210 watts into 2 ohms
2 x 167 watts into 4 ohms
THD: 0.008% at rated power
Damping factor: 50 (at 8 ohms)
Input (Sensitivity / Impedance)
Phono (MM): 2.5 mV / 50 kilohms
Phono (MC): 160 microvolts / 50 kilohms
Tuner, CD, CD directly, Aux, Tape: 150 mV / 50 kilohms
Tape Rec .: 150 mV / 1.5k
Output (Level / Impedance):
Frequency response: 2-50000 Hz (+0, -1 dB)
Tone control:
Contra Bass: ± 10 dB (at 20 Hz)
Bass: ± 10 dB (at 70 Hz)
Treble: ± 8 dB (at 20 kHz)
Loudness: No
Subsonic: NO
Mute: yes (-20 dB)
Direct / Line Straight: yes
