Specifications

Radio:
Tuning Range: 87.5 MHz to 108 MHz
Sensitivity: 3 µV for 3 dB below limiting
Better than 1.5 µV for 26 dB SNR
Amplifier:
Freq. Response: 30Hz - 20kHz, ±1.5 dB at 5 Watts
RMS Power Out: 35 watts into 4Ω less than 1% distortion.
30 watts into 4Ω less than 0.1% distortion.
25 watts into 8Ω less than 1% distortion.
16 watts into 15Ω less than 1% distortion.
Power Bandwidth: Exceeds response bandwidth of amplifier.
Tone Controls: Bass ± 13 dB at 50 Hz
Treble ± 17 dB tp +10 dB at 50 Hz
Filters: Rumble -11 dB at 25 kHz
Treble - 11 dB at 16 kHz
I/P Sensitivities 30 W Magnetic 2 mV into 50 kΩ
RIAA with 1 dB from 40 Hz - 20 kHz
Aux. 60 mV into 600 kΩ
Tape 320 mV into 50 kΩ
Tape O/P 500 mV into 330 kΩ
Unweighted hum & noise Better than -80 dB at 35 W Tape and Aux.
Better than -66 dB at 35 W Magnetic PU.
Crosstalk Better than -45dB(40Hz-12kHz) all inputs, between channels Better than -60dB
