Nominal impedance 8 ohm
Dimensional category 12.5 inch
Frequency coverage type Low, Midbass, Midrange
Manufacturer sensitivity 102 dB
Calculated sensitivity 98.66 dB
Nominal power handling 600 W
Max power handling 1200 W
Bandwidth 60÷3000 Hz
Sd 531 cm²
Mms 61 gr
Cms 144 µm/N
Le 0.69 mH
Re 5.5 ohm
BL 24.4 T.m
Fs 54 Hz
Qes 0.19
Qms 8.4
Qts 0.19
Vas 58 L
Xmax ±3.5 mm
EBP 284 Hz
Zmin 5.7 ohm
Fs / Qts 284 Hz
Vas * Qts² 2.1 L
Efficiency 4.5 %
Calculated efficiency 4.62 %
Weight ~5.6 kg
Voice coil diameter 4 inch
Outside diameter 315 mm
Baffle cutout diameter 282 mm
Depth 116 mm
Front thickness 18 mm
Depth after front 98 mm
Front chape Cylindrical
Magnet type Neodymium
Basket masterial Aluminium
Winding material Copper
Voice coil former Glass fiber
Surround shape Double roll
Surround material Cloth
Dome material Paper
Cone shape Curvilinear
